MK-8-8080C-X

As a leading aluminum profile manufacturer, we are proud to present the MK-8-8080C-X, a robust 80x80mm profile from our PG80 series. Precision-engineered from high-grade Aluminum Alloy 6063-T5, this profile offers exceptional structural integrity and durability. Its silver anodized finish not only provides a sleek, professional appearance but also offers excellent corrosion resistance with a 0-15μm surface treatment. Designed with large R90 corner radii, the MK-8-8080C-X delivers superior strength and load-bearing capacity, making it an ideal choice for heavy-duty industrial frames, machine bases, workstations, and automation systems. With a mass of 3.210 kg/m and high moments of inertia (Lx: 64.33 cm⁴, Ly: 64.62 cm⁴), this profile ensures minimal deflection under load, guaranteeing long-lasting performance and stability in demanding applications.

Frequently Asked Questions

Q1: What is the standard length available for the MK-8-8080C-X profile?
A: As a manufacturer, we can supply this profile in custom lengths to meet your project requirements. Standard stock lengths are typically 6 meters, but we can cut to your exact specifications.

Q2: Can this profile be anodized in different colors?
A: Yes, while the standard finish is silver anodized, we offer customization options including black anodizing or other colors upon request. Please contact our sales team for specific color availability and minimum order quantities.

Q3: What type of connectors or accessories are compatible with the MK-8-8080C-X?
A: This profile is part of the 80 Series system, compatible with our full range of 80 series accessories, including corner brackets, T-nuts, bolts, and joining plates. We can also provide custom machining such as drilling and tapping to facilitate assembly.

Specification	Details
Material	Aluminum Alloy 6063-T5
Surface Treatment	0-15μm Anodized (Silver)
Moment of Inertia (Lx / Ly)	64.33 cm⁴ / 64.62 cm⁴
Mass	3.210 kg/m
Moment of Resistance (Wx / Wy)	16.08 cm³ / 16.12 cm³
